Standard&Protocol
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab
Interface
24*10/100/1000M auto-negotiation RJ45 ports (Auto MDI/MDIX)
Transmission Media
10Base-T: Cat. 3 UTP or better 100Base-TX: Cat.5 UTP or better
1000Base-T: Cat.5e UTP or better
1000Base-T: Cat.5e UTP or better
Forwarding Speed
10Mbps: 14880pps 100Mbps: 148800pps 1000Mbps: 1488000pps
Power Supply
Input: AC:100-240V
50/60Hz
50/60Hz
Lightning Protection
6kV in Common Mode Protection for all ports
Lightning Level 6kV in Common Mode, 4kV in Differential Mode Protection for power supply
Lightning Level 6kV in Common Mode, 4kV in Differential Mode Protection for power supply
Dimension
440mm *178mm *44mm(L*W*H)
LED indicator
1* Power, 24* Link/Act
Switching Capacity
48Gbps
MAC Address Table
8K
Power Consumption
Maximum : 13W (220V)
Store & Forward
Yes
Access Control
CDMA/CD
MAC Address Learning
Automatic update
Temperature
Operating Temperature: 0?~40?
Storage Temperature: -40?~70?
Storage Temperature: -40?~70?
Humidity
Operating Humidity: 10%~90% non-condensing
Humidity Storage Humidity: 5%~90% non-condensing
Humidity Storage Humidity: 5%~90% non-condensing
Certification
CE , FCC , RoHS
Related Products
TEG1008D 8-Port Gigabit Ethernet Switch
S16 16-Port 10/100Mbps Desktop Switch
TEG1016D 16-Port Gigabit Ethernet Switch
S16 16-Port 10/100Mbps Desktop Switch
TEG1016D 16-Port Gigabit Ethernet Switch
Compatible OS
Windows 8 32/64 bit , Windows 7 32/64 bit , Windows xp 32/64 bit ,Compatible OS Linux , MAC OS
